Dolph Microwave has developed a line of four port double ridge waveguide magic tees & hybrids power combiners and dividers covering waveguide sizes WRD-200 to WRD-700. These Magic Tees & Hybrids can vectorially add, subtract or divide two signals. E-plane to H-plane Isolation is a function of the symmetry which is carefully balanced on each […]

Dual channel rotary joint are used to transmit microwave energy from stationary lines to rotating lines. Dolph Microwave offers a standard product line of Rotary Joints covering waveguide sizes WR28 thru WR284.Rotary Joints (rotary couplers) are used to transmit microwave energy from stationary lines to rotating lines. Available styles are defined by physical geometry as

Launcher and Tapered Waveguide for 3kw microwave magnetron for LG MAGETRON 2M290   Model: DH-2226WA150PPA+DH-26MECL100A10 Frequency Range: 2450±50 MHz VSWR (Max.): ≤1.05:1 Handling Power: 3 KW, CW Waveguide Type: WR340/WR430 Flange: FDP26/FDP22 Material: Aluminum Inside Finish: Chromate conversion / Silver plating Outside Finish: Anticorrosion black paint Any interested items, please contact.

If you have a microwave source of 2.45GHz, want to concentrate microwave energy in a chamber using Antenna. Then WR340 WG Mode Converter/Antenna must be what you need. WR340 WG Mode Converter/Antenna for microwave plasma CVD application. Model：DH-26WGMCTE10/TM01 (WR340) Frequency Range：2450±50 MHz VSWR (Max.)：≤1.2:1 Handling Power：6 KW, CW Mode Converter：TE10-TM01 Water Flow：3-5 L/min Waveguide Type：WR340
