A waveguide tee is a three-port device used in microwave systems to split or combine signals. It comes in various forms, including E-plane, H-plane, and Magic tees, each designed for specific applications. This component is essential for directing RF energy in multiple directions, enhancing system design flexibility.
Dolph Microwave supplies 3-port E-plane and H-plane tees plus 4-port magic hybrid tees from WR2300 to WR10, covering 0.32–112 GHz. Standard catalog models include multiple flange configurations, with custom mechanical and electrical specifications available. Send your operating frequency, waveguide size, tee type, flange and performance targets for model selection.
A 4-port coupler for matching, balance and isolation. With the E-plane port used as input, the two collinear outputs are 180° out of phase; with the H-plane port as input, the outputs are in phase. Equal-amplitude, in-phase signals applied to the two collinear ports combine at the H-plane port and cancel at the E-plane port.
Catalog values: 20% operating bandwidth, E-port VSWR 1.15:1, H-port VSWR 1.2:1, ±0.25 dB unbalance, 35 dB E/H isolation and 20 dB same-arm isolation.
A 3-port tee with the auxiliary-arm junction on the broad wall of the main waveguide. It is available throughout the catalog range from WR2300 to WR10.
Catalog values: 100% operating bandwidth, E-port VSWR 1.15:1 and ±0.25 dB E/H unbalance.
A 3-port tee with the auxiliary-arm junction on the narrow wall of the main waveguide. It is available throughout the catalog range from WR2300 to WR10.
Catalog values: 100% operating bandwidth, H-port VSWR 1.15:1 and ±0.25 dB E/H unbalance.
Standard models span WR2300 to WR10; detailed electrical and flange values are listed below.
| Model | Freq. Range (GHz) | Operating BW | WG Size | VSWR | Unbalance E/H (dB) | Isolation (dB) | Waveguide Type | Flanges Type | Datasheet | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| E-Port | H-Port | E/H | Same Arms | Cover | Grooved | STEP | |||||||
| DH-3WMT… | 0.32-0.49 | 20% | WR2300 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UDR3 | PDR3 | STEP | |
| DH-3WET… | 0.32-0.49 | 100% | WR2300 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UDR3 | PDR3 | STEP | |
| DH-3WHT… | 0.32-0.49 | 100% | WR2300 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UDR3 | PDR3 | STEP | |
| DH-4WMT… | 0.35-0.53 | 20% | WR2100 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UDR4 | PDR4 | STEP | |
| DH-4WET… | 0.35-0.53 | 100% | WR2100 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UDR4 | PDR4 | STEP | |
| DH-4WHT… | 0.35-0.53 | 100% | WR2100 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UDR4 | PDR4 | STEP | |
| DH-5WMT… | 0.41-0.62 | 20% | WR1800 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UDR5 | PDR5 | STEP | |
| DH-5WET… | 0.41-0.62 | 100% | WR1800 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UDR5 | PDR5 | STEP | |
| DH-5WHT… | 0.41-0.62 | 100% | WR1800 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UDR5 | PDR5 | STEP | |
| DH-6WMT… | 0.49-0.75 | 20% | WR1500 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UDR6 | PDR6 | STEP | |
| DH-6WET… | 0.49-0.75 | 100% | WR1500 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UDR6 | PDR6 | STEP | |
| DH-6WHT… | 0.49-0.75 | 100% | WR1500 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UDR6 | PDR6 | STEP | |
| DH-8WMT… | 0.64-0.98 | 20% | WR1150 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UDR8 | PDR8 | STEP | |
| DH-8WET… | 0.64-0.98 | 100% | WR1150 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UDR8 | PDR8 | STEP | |
| DH-8WHT… | 0.64-0.98 | 100% | WR1150 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UDR8 | PDR8 | STEP | |
| DH-9WMT… | 0.75-1.15 | 20% | WR975 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UDR9 | PDR9 | STEP | |
| DH-9WET… | 0.75-1.15 | 100% | WR975 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UDR9 | PDR9 | STEP | |
| DH-9WHT… | 0.75-1.15 | 100% | WR975 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UDR9 | PDR9 | STEP | |
| DH-12WMT… | 0.96-1.46 | 20% | WR770 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UDR12 | PDR12 | STEP | |
| DH-12WET… | 0.96-1.46 | 100% | WR770 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UDR12 | PDR12 | STEP | |
| DH-12WHT… | 0.96-1.46 | 100% | WR770 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UDR12 | PDR12 | STEP | |
| DH-14WMT… | 1.13-1.73 | 20% | WR650 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UDR14 | PDR14 | STEP | |
| DH-14WET… | 1.13-1.73 | 100% | WR650 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UDR14 | PDR14 | STEP | |
| DH-14WHT… | 1.13-1.73 | 100% | WR650 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UDR14 | PDR14 | STEP | |
| DH-18WMT… | 1.45-2.20 | 20% | WR510 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UDR18 | PDR18 | STEP | |
| DH-18WET… | 1.45-2.20 | 100% | WR510 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UDR18 | PDR18 | STEP | |
| DH-18WHT… | 1.45-2.20 | 100% | WR510 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UDR18 | PDR18 | STEP | |
| DH-22WMT… | 1.72-2.61 | 20% | WR430 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UDR22 | PDR22 | STEP | |
| DH-22WET… | 1.72-2.61 | 100% | WR430 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UDR22 | PDR22 | STEP | |
| DH-22WHT… | 1.72-2.61 | 100% | WR430 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UDR22 | PDR22 | STEP | |
| DH-26WMT… | 2.17-3.30 | 20% | WR340 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UDR26 | PDR26 | STEP | |
| DH-26WET… | 2.17-3.30 | 100% | WR340 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UDR26 | PDR26 | STEP | |
| DH-26WHT… | 2.17-3.30 | 100% | WR340 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UDR26 | PDR26 | STEP | |
| DH-32WMT… | 2.60-3.95 | 20% | WR284 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UDR32 | PDR32 | STEP | |
| DH-32WET… | 2.60-3.95 | 100% | WR284 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UDR32 | PDR32 | STEP | |
| DH-32WHT… | 2.60-3.95 | 100% | WR284 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UDR32 | PDR32 | STEP | |
| DH-40WMT… | 3.22-4.90 | 20% | WR229 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UDR40 | PDR40 | STEP | |
| DH-40WET… | 3.22-4.90 | 100% | WR229 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UDR40 | PDR40 | STEP | |
| DH-40WHT… | 3.22-4.90 | 100% | WR229 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UDR40 | PDR40 | STEP | |
| DH-48WMT… | 3.94-5.99 | 20% | WR187 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UDR48 | PDR48 | STEP | |
| DH-48WET… | 3.94-5.99 | 100% | WR187 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UDR48 | PDR48 | STEP | |
| DH-48WHT… | 3.94-5.99 | 100% | WR187 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UDR48 | PDR48 | STEP | |
| DH-58WMT… | 4.64-7.05 | 20% | WR159 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UDR58 | PDR58 | STEP | |
| DH-58WET… | 4.64-7.05 | 100% | WR159 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UDR58 | PDR58 | STEP | |
| DH-58WHT… | 4.64-7.05 | 100% | WR159 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UDR58 | PDR58 | STEP | |
| DH-70WMT… | 5.38-8.17 | 20% | WR137 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UDR70 | PDR70 | STEP | |
| DH-70WET… | 5.38-8.17 | 100% | WR137 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UDR70 | PDR70 | STEP | |
| DH-70WHT… | 5.38-8.17 | 100% | WR137 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UDR70 | PDR70 | STEP | |
| DH-84WMT… | 6.57-9.99 | 20% | WR112 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UDR84/UBR84 | PDR84/PBR84 | STEP | |
| DH-84WET… | 6.57-9.99 | 100% | WR112 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UDR84/UBR84 | PDR84/PBR84 | STEP | |
| DH-84WHT… | 6.57-9.99 | 100% | WR112 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UDR84/UBR84 | PDR84/PBR84 | STEP | |
| DH-100WMT… | 8.20-12.4 | 20% | WR90 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UDR100/UBR100 | PDR100/PBR100 | STEP | |
| DH-100WET… | 8.20-12.4 | 100% | WR90 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UDR100/UBR100 | PDR100/PBR100 | STEP | |
| DH-100WHT… | 8.20-12.4 | 100% | WR90 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UDR100/UBR100 | PDR100/PBR100 | STEP | |
| DH-120WMT… | 9.84-15.0 | 20% | WR75 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UBR120 | PBR120 | STEP | |
| DH-120WET… | 9.84-15.0 | 100% | WR75 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UBR120 | PBR120 | STEP | |
| DH-120WHT… | 9.84-15.0 | 100% | WR75 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UBR120 | PBR120 | STEP | |
| DH-140WMT… | 11.9-18.0 | 20% | WR62 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UBR140 | PBR140 | STEP | |
| DH-140WET… | 11.9-18.0 | 100% | WR62 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UBR140 | PBR140 | STEP | |
| DH-140WHT… | 11.9-18.0 | 100% | WR62 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UBR140 | PBR140 | STEP | |
| DH-180WMT… | 14.5-22.0 | 20% | WR51 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UBR180 | PBR180 | STEP | |
| DH-180WET… | 14.5-22.0 | 100% | WR51 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UBR180 | PBR180 | STEP | |
| DH-180WHT… | 14.5-22.0 | 100% | WR51 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UBR180 | PBR180 | STEP | |
| DH-220WMT… | 17.6-26.7 | 20% | WR42 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UBR220 | PBR220 | STEP | |
| DH-220WET… | 17.6-26.7 | 100% | WR42 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UBR220 | PBR220 | STEP | |
| DH-220WHT… | 17.6-26.7 | 100% | WR42 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UBR220 | PBR220 | STEP | |
| DH-260WMT… | 21.7-33.0 | 20% | WR34 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UBR260 | PBR260 | STEP | |
| DH-260WET… | 21.7-33.0 | 100% | WR34 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UBR260 | PBR260 | STEP | |
| DH-260WHT… | 21.7-33.0 | 100% | WR34 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UBR260 | PBR260 | STEP | |
| DH-320WMT… | 26.5-40.0 | 20% | WR28 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | UBR320 | PBR320 | STEP | |
| DH-320WET… | 26.5-40.0 | 100% | WR28 | 1.15:1 | / | ±0.25 | / | / | E-Tee | UBR320 | PBR320 | STEP | |
| DH-320WHT… | 26.5-40.0 | 100% | WR28 | / | 1.15:1 | ±0.25 | / | / | H-Tee | UBR320 | PBR320 | STEP | |
| DH-400WMT… | 32.9-50.1 | 20% | WR22 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | FUGP400/UG-383U/M | STEP | ||
| DH-400WET… | 32.9-50.1 | 100% | WR22 | 1.15:1 | / | ±0.25 | / | / | E-Tee | FUGP400/UG-383U/M | STEP | ||
| DH-400WHT… | 32.9-50.1 | 100% | WR22 | / | 1.15:1 | ±0.25 | / | / | H-Tee | FUGP400/UG-383U/M | STEP | ||
| DH-500WMT… | 39.2-59.6 | 20% | WR19 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | FUGP500/UG-383U/M | STEP | ||
| DH-500WET… | 39.2-59.6 | 100% | WR19 | 1.15:1 | / | ±0.25 | / | / | E-Tee | FUGP500/UG-383U/M | STEP | ||
| DH-500WHT… | 39.2-59.6 | 100% | WR19 | / | 1.15:1 | ±0.25 | / | / | H-Tee | FUGP500/UG-383U/M | STEP | ||
| DH-620WMT… | 49.8-75.8 | 20% | WR15 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | FUGP620/UG-385U/M | STEP | ||
| DH-620WET… | 49.8-75.8 | 100% | WR15 | 1.15:1 | / | ±0.25 | / | / | E-Tee | FUGP620/UG-385U/M | STEP | ||
| DH-620WHT… | 49.8-75.8 | 100% | WR15 | / | 1.15:1 | ±0.25 | / | / | H-Tee | FUGP620/UG-385U/M | STEP | ||
| DH-740WMT… | 60.5-91.9 | 20% | WR12 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | FUGP740/UG-387U/M | STEP | ||
| DH-740WET… | 60.5-91.9 | 100% | WR12 | 1.15:1 | / | ±0.25 | / | / | E-Tee | FUGP740/UG-387U/M | STEP | ||
| DH-740WHT… | 60.5-91.9 | 100% | WR12 | / | 1.15:1 | ±0.25 | / | / | H-Tee | FUGP740/UG-387U/M | STEP | ||
| DH-900WMT… | 73.8-112 | 20% | WR10 | 1.15:1 | 1.2:1 | ±0.25 | 35 | 20 | Magic Tee | FUGP900/UG-387U/M | STEP | ||
| DH-900WET… | 73.8-112 | 100% | WR10 | 1.15:1 | / | ±0.25 | / | / | E-Tee | FUGP900/UG-387U/M | STEP | ||
| DH-900WHT… | 73.8-112 | 100% | WR10 | / | 1.15:1 | ±0.25 | / | / | H-Tee | FUGP900/UG-387U/M | STEP | ||
Use the code structure to define waveguide size, tee type, flange and material before release.
Finish note: All Dolph-MW models include a Surtec/corrosion-protection treatment and are painted flat black. Flanges are unplated, polished and Surtec treated. Other finishes and paint colors are available upon request. The published general summary also states Aluminum 6061-T6 with chromate conversion finish and gray epoxy enamel; confirm the final material and finish for the selected part number before order release.
Standard catalog models can be selected from the table above. For non-standard interfaces or electrical targets, Dolph Microwave also supports custom mechanical and electrical specifications.
Dolph Microwave states a one-year warranty from the date of delivery for defects in material and workmanship under its published warranty terms.
Dolph Microwave warrants our products to be free from defective material and workmanship for a period of one year from the date of delivery. All defective parts will be replaced and repair work required by normal use will be performed, without charge, within this one year period. This warranty shall be exclusive and in lieu of all other warranties expressed or implied.
