[Plasma Components] Water cooled Stub Tuner, WR340, 6kW/3kW

Water Cooled Type waveguide tuners are waveguide components used to match the load impedance with the source impedance. They minimize the amount of reflected power, providing the most efficient coupling of power to the load. Dolph Microwave supplies both manual 3- and 4-stub tuners, electrical and auto tuners. Tuners utilize manual tuning and lock simply. Tuners are generally used in applications where the load impedance varies significantly due to variations in the load.

• Model: DH-26WCW3ST6PPA
• Frequency Range: 2450±25MHz
• VSWR: 1.1-10
• Power Handling: 3 kW/6 kW
• Cooling: Water Cooled/ Air
• Tuning: Manual
• Waveguide Type: WR340
• Flange Type: FDP26 (Cover)
• Material: Aluminum
• Inside Finish: Conductive Oxidation
• Outside Finish Anticorrosion Black Paint
• Size: L 236*W 138*H 157 mm
